Herzbach MODUL7 PUSH thermostat finish set 70.702003.1.09 2 consumers stainless steel

herzbach MODUL7 PUSH thermostat color set for 2 consumers

for use in the bath / shower area consisting of:

MODUL7 Thermostat
-Rotatable thermostat cartridge to regulate the temperature range from 20°C-55°C
-Manually unlockable hot water lock at 38°C as scalding protection
-Stainless steel operating handle
-Stainless steel module cover Ø 70 mm with sketched temperature scale

2 MODUL7 PUSH flow valves
-Start + stop the water flow by pressing the PUSH flow valves
-Smooth and stepless volume control with comfortable 90° operating radius
-Stainless steel operating handles
-Stainless steel module panels Ø 70 mm

MODUL7 shower holder set
-Shower connection bend with concealed hose connection
-MODUL7 shower hose 1500 mm with rotating cone
-1-jet stainless steel hand shower
-Stainless steel module cover Ø 70 mm

Module center distance 105 mm
Min. operating pressure: 0.5 bar
Max. operating pressure: 5 bar
integrated backflow preventers and dirt traps
intrinsically safe against backflow
Final assembly set for attachment to MODUL7 PUSH thermostat installation body (70.720003.1.09)
Surface stainless steel matt brushed
Manufacturer herzbach / Product group M7 IX
Item No. 70.702003.1.09
