Herzbach MODUL7 PUSH thermostat set P-TF2 70.703723.1.01 TWIN FLOW chrome

herzbach MODUL7 PUSH thermostat set P-TF2 with TWIN FLOW and hand shower

for use in the shower area consisting of:

SET SCOPE
70.730003.1.09 MODUL7 PUSH thermostat installation body
70.703003.1.01 MODUL7 thermostat color set for 3 consumers
11.044277.1.01 LIVING SPA wall-mounted rain shower TWIN FLOW

MODUL7 PUSH thermostat installation body
-for 3 consumers

MODUL7 thermostat
-Rotatable thermostat cartridge to regulate the temperature range from 20°C-55°C
-Manually unlockable hot water lock at 38°C as scalding protection
-Brass control handle
-Brass module cover Ø 70 mm

2 MODUL7 PUSH flow valves
-Start + stop the water flow by pressing the PUSH flow valves
-Smooth and infinitely variable quantity regulation with a comfortable 90° operating radius
-Brass control handles
-Brass module panels Ø 70 mm

MODUL7 shower holder set
-Shower connection elbow with concealed hose connection
-MODUL7 shower hose 1500 mm with rotating cone
-1-jet brass hand shower
-Brass module cover Ø 70 mm

LIVING SPA wall-mounted rain shower TWIN FLOW multifunction 2
Spray type: Rain soft / Rain intense
Dimensions Regenfeld 300 mm x 300 mm
with fastening material for surface-mounting on the wall
Clean effect

Module center distance 105 mm
Min. operating pressure: 0.5 bar
max. operating pressure: 5 bar
Integrated backflow preventers and dirt traps
intrinsically safe against backflow
Chrome surface
Manufacturer herzbach / product group M7 SETS CHROME
Item No. 70.703723.1.01
