Ideal Standard Gusto wall-mounted kitchen faucet A7817A5 magnetic gray, with sensor liquid soap dispenser, kit 2
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 100
Questions about the article?
+49 241-51832611
Mon. - Thu. 8.00 am to 6.00 pm, Fri. 8.00 am to 3.00 pm
Details
Ideal Standard Gusto wall-mounted kitchen tap A7817A5
- DN 15
- 360° swiveling pipe spout (L-shape) with aerator
- Projection 232 mm
- Spout height 334 mm
- usable spout height 293 mm
- flexible connection hoses G3/8
- Metal operating lever
- Fastening from below with EASY-Fix+ for kitchen fittings
- Red/blue marking on the fitting body
- Ø 28 mm FirmenFlow cartridge with ceramic sealing disks
- Cartridge swivel range 100°
- tested for 500,000 cycles (1 cycle corresponds to 11 lever movements)
- Integrated fat reservoir (food compatible)
- maximum temperature resistance up to 95 °C (not suitable for continuous operation)
- Integrated hot water temperature limiter
- required hole diameter 35 mm
- maximum thickness of the worktop 40 mm
- separate soap dispenser unit consisting of a pump
- Soap container (capacity 1000 ml)
- Cable and soap hose for using liquid soap or detergent
- Mains operation 220 V
- Triggering the pump mechanism by activating the pressure sensor at the front of the spout
- Soap outlet at the pipe outlet behind the aerator
- The soap dispenser unit can be installed up to a maximum of 1 m away from the fitting
- 220 V plug-in power supply with 2 m connection cable
- Lifespan test EN 817. Noise behavior DIN 4109
- Group 1
