Ideal Standard Joy 3-hole basin mixer BC788A5 Magnetic Gray, for rim-mounting, without spout
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 100
Questions about the article?
+49 241-51832611
Mon. - Thu. 8.00 am to 6.00 pm, Fri. 8.00 am to 3.00 pm
Details
Ideal Standard Joy 3-hole basin mixer BC788A5
- DN 15
- with switching valve for filling the tub via drain and overflow fittings
- automatic reset from hand shower to bathtub
- Support surface Ø 48 mm
- Control lever made of metal
- without red / blue marking
- Hand shower holder with metal
- Bar hand shower 8 l / min
- Flow
- 2000 / 2 "x 1750 mm
- Check Valves
- Projection 222 mm
- Ø 38 mm cartridge with ceramic sealing washers
- Cartridge Stainless Steel from Stainless Steel
- Swivel range 100 grand
- tested to 500,000 cycles (one cycle consists of a total of 11 different lever movements)
- maximum temperature resistance up to 95 ° C (not suitable for continuous operation)
- integrated grease reservoir (food safe)
- integrated hot water temperature limiter
- Can be mounted on the tub rim without a mounting plate
- Endurance test EN 817
- Noise behavior DIN 4109
- Green 2000 pipe 2000
