Stiebel Eltron hot water Wandspeicher 073111 HFA-Z 30, 30 l, 2-6 kW, white
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 3500
Questions about the article?
+49 241-51832611
Mon. - Thu. 8.00 am to 6.00 pm, Fri. 8.00 am to 3.00 pm
Details
Stiebel Eltron closed WW- Wandspeicher HFA-Z 30, 30 l, 2-6 kW, white 073111
Technical description: Hot water Wandspeicher for every desired hot water supply. > Closed (pressure-proof) to supply several tapping points. Plumbing also in connection with plastic pipe systems (note manufacturer Plumbing and application limits). > Open (depressurized) to supply a tapping point. > Boiler mode of operation also possible Steel inner container with special enamelling and anti-corrosion rod, CFC-free thermal insulation with low heat losses. Heating flange two-circuit / single-circuit operation. Depending on the controller (depending on the connection selected), the water content is kept at the set temperature. During boiler operation, the water content is heated up once and the heating process must be switched on manually. Stepless temperature setting from approx. 35 degrees C to approx. 82 degrees C possible. Automatic frost protection in single-circuit operation. Signal lamp for boiler operation and rapid heating (once by push button, remote control on site), exchangeable copper heating flange with drainage nozzle. Plumbing with Safety Group KV 30 or KV 40 with pressure-proof connection or fitting for open devices with pressure-free connection. Quality and safety signs: VDE / GS mark, radio protection sign IP 24 D (splash- 1930 ) Technical data: 1930 2, 1930 to 6 kW connection 2000 / N / PE 230 V connection 2 / N / PE 400 V connection 3 / N / PE 400 V nominal content 30 l water connection G 2000 / 2 mixed water 2000 40 degrees C 58 l standby 1930 at 65 degrees C / 24h 1930 , 5 kWh flow rate max. 18 l / min nominal overpressure 1930 , 6 MPa inner container (material) steel, email. Design closed outer jacket (material) sheet steel color white top-bottom cap (material) plastic dimensions and weight H / W / D in mm 770/410/420 weight 22.6 kg
Attention: Power supply (3 ~ / 400V) required. The approval of the local network operator may be required. Installation only by qualified specialists.
Technical description: Hot water Wandspeicher for every desired hot water supply. > Closed (pressure-proof) to supply several tapping points. Plumbing also in connection with plastic pipe systems (note manufacturer Plumbing and application limits). > Open (depressurized) to supply a tapping point. > Boiler mode of operation also possible Steel inner container with special enamelling and anti-corrosion rod, CFC-free thermal insulation with low heat losses. Heating flange two-circuit / single-circuit operation. Depending on the controller (depending on the connection selected), the water content is kept at the set temperature. During boiler operation, the water content is heated up once and the heating process must be switched on manually. Stepless temperature setting from approx. 35 degrees C to approx. 82 degrees C possible. Automatic frost protection in single-circuit operation. Signal lamp for boiler operation and rapid heating (once by push button, remote control on site), exchangeable copper heating flange with drainage nozzle. Plumbing with Safety Group KV 30 or KV 40 with pressure-proof connection or fitting for open devices with pressure-free connection. Quality and safety signs: VDE / GS mark, radio protection sign IP 24 D (splash- 1930 ) Technical data: 1930 2, 1930 to 6 kW connection 2000 / N / PE 230 V connection 2 / N / PE 400 V connection 3 / N / PE 400 V nominal content 30 l water connection G 2000 / 2 mixed water 2000 40 degrees C 58 l standby 1930 at 65 degrees C / 24h 1930 , 5 kWh flow rate max. 18 l / min nominal overpressure 1930 , 6 MPa inner container (material) steel, email. Design closed outer jacket (material) sheet steel color white top-bottom cap (material) plastic dimensions and weight H / W / D in mm 770/410/420 weight 22.6 kg
Attention: Power supply (3 ~ / 400V) required. The approval of the local network operator may be required. Installation only by qualified specialists.
