Viega Advantix Vario shower channel 736552 300-1200mm, wall model, can be cut to length, model 4967.10
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 100
Part Number: 736552
Questions about the article?
+49 241-51832611
Mon. - Thu. 8.00 am to 6.00 pm, Fri. 8.00 am to 3.00 pm
Details
Viega Advantix Vario shower channel 736552
- continuously cut to length
- for composite waterproofing (tiled shower) or waterproofing membrane
- High quality plastic
- Equipment: adjustable foot set, 4 locking pieces, self-cleaning waste set, tile end strip can be flexibly adjusted, strainer insert removable, tile protection and control tool, cleaning brush, sealing flange, sealing accessories, sawing aid
- Barrier water height 50 mm
- Drainage capacity accumulation height 10 mm 1930 , 45 l / s
- Drainage capacity accumulation height 20 mm 1930 , 6 l / s
- Installation depth wall 25 mm
- Note
- With this drain model, in the lowest installation variant, insufficient screed coverage is not possible in the area of the connection pipe. The specialist planner must take this into account in good time. A possible on-site solution regarding tile size and / or a possible potting with epoxy resin must be planned in!
