Wilo DrainLift MINI3-XS/WC-EF small sewage lifting station 6095128 ready for connection

Wilo small sewage lifting station 6095128

• DrainLift MINI3-XS/WC-EF
• according to EN 12050-3
• ready for connection
• compact
• fully submersible lifting station
• Submersible motor pump
• Level detection by vertical float switch
• integrated ventilation in the lid
• Activated carbon filter

Up to five connections are available:

• 1x inlet 50 mm (DN 40), without backflow preventer, directed upwards, closed at the factory.
• 2x inlets 50/63 mm (DN 40/50), with backflow preventer, horizontal to the left and right, open at the factory.
• 1x toilet connection 110 mm (DN 100), facing forward, open at the factory. - If required, the toilet connection can be made horizontally to the right. The corresponding opening is closed at the factory.
• 1x pressure connection 40/50 mm (DN 32/40), with non-return valve, facing upwards, open at the factory.
•
